HOLT IC航空電子設備 MIL-STD-1553 集成終端
發布時間：2021-03-09 17:03:44 瀏覽：2732
HOLT IC最新的MIL-STD-1553系列Mamba TM為客戶提供了世界上最小的解決方案，可選擇用于常見應用配置的設備以節省成本。HOLT IC提供BC / MT / RT，BC / RT，RT / MT和RT組合。所有設備都是片上集成收發器，封裝在48針塑料QFP或6毫米x 6毫米QFN中，帶有4線40MHz主機串行外圍接口（SPI）。
HOLT IC是航天工業集成電路的主要供應商。20年來，HOLT IC一直在為世界各國的商業和軍事客戶生產制造數據總線和顯示驅動芯片機器設備。從F16到350，HOLT IC主要是航空調節、導航欄、發動機管理、通訊、安全防護設備和航空娛樂系統。
深圳市立維創展科技有限公司，持續提供HOLT IC預定渠道，部分型號備有現貨庫存，歡迎咨詢。
詳情了解HOLT IC請點擊：/brand/55.html
或聯系我們的銷售工程師：0755-83642657 QQ: 2295048674
Device | Device Type | Description |
HI-6138 | MAMBATM
BC / RT / MT | World's smallest solution. 3.3V operation. BC, MT and RT may operate concurrently. Integrated dual transceivers. 8K x 17 RAM with parity, 40 MHz Serial Peripheral host Interface (SPI). |
HI-6137 | MAMBATM
BC / RT | World's smallest solution. 3.3V operation. BC and RT may operate concurrently. Integrated dual transceivers. 8K x 17 RAM with parity, 40 MHz Serial Peripheral host Interface (SPI). |
HI-6136 | MAMBATM
RT / MT | World's smallest solution. 3.3V operation. RT and MT may operate concurrently. Integrated dual transceivers. 8K x 17 RAM with parity, 40 MHz Serial Peripheral host Interface (SPI). |
HI-6135 | MAMBATM
RT | World's smallest solution. 3.3V operation. Integrated dual transceivers. 8K x 17 RAM with parity, 40 MHz Serial Peripheral host Interface (SPI). |
HI-2130 | BC / MT / 2RT | World’s smallest MIL-STD-1553 fully integrated terminal solution. Protocol, RAM, dual transceivers and dual transformers in a single 15mm x 15mm package. |
HI-6130 | BC / MT / 2RT | 3.3V operation. BC, MT and two RTs may operate concurrently. Integrated dual transceivers. 32K x 16 RAM with optional error detection/correction, 16-bit parallel host interface. |
HI-6131 | BC / MT / 2RT | Equivalent to HI-6130 with reduced package size and SPI host interface. |
HI-62003 | BC / RT / MT | BC/RT/MT or RT/MT Modes, ECC SRAM and integrated dual transceivers. Register-level software compatible with competitor legacy devices. |
HI-62023 | Remote Terminal | Remote Terminal, ECC SRAM and integrated dual transceivers. Register-level software compatible with competitor legacy devices. |
HI-62025 | Remote Terminal | Remote Terminal, ECC SRAM and integrated dual transceivers. Register-level software compatible with competitor legacy devices. |
HI-6140 | BC / MT / RT 10Mbps | 3.3V, 10Mbit/sec, EBR-1553 operation. BC, MT or RT. 32K x 16 RAM with optional error detection/correction, 16-bit parallel host interface. |
HI-6120 | Remote Terminal | 3.3V operation. Integrated dual transceivers. 32K x 16 RAM, illegal command detection, data buffering, time tag, optional auto initialization, 16-bit parallel host interface. |
HI-6121 | Remote Terminal | Equivalent to HI-6120 with reduced package size and SPI host interface. |
HI-6110 | BC / MT / RT | 3.3V operation. Integrated dual transceivers. Single message processor. |
